Newtek 3Play 1 Replay System

 available to buy now

Newtek 3Play® 3P1 offers high-quality replay at an affordable price. With native IP inputs and outputs via NDI®, and traditional 3G-SDI connectivity with support for resolutions up to 1080p 60resolution, 3Play 3P1 is made for live event production regardless of infrastructure.

An intuitive user interface and a complete set of real-time capabilities for live coverage, replay, training, analysis, and telestration makes 3Play 3P1 more ready for events than other replay systems.

Specifications

Specifications

  • Video Input: 4 x simultaneous external video inputs, supporting any combination of compatible sources
  • Network Video Input: 4 x resolution-independent IP video inputs via NDI®
  • SDI Video Input: 4 x 3G/HD/SD-SDI connections supporting video input in any combination of standard formats, resolutions, and frame rates
  • Video Output: 2 x session-format video outputs, with simultaneous delivery via IP and SDI
  • Network Video Output: 2 x session-format IP video outputs via NDI®
  • SDI Video Output: 4 x 3G/HD/SD-SDI connections supporting redundant delivery of 2x session-format video outputs
  • Multiview Output: 1 x DVI user interface with multiviewer
    1 x HDMI multiviewer
    1 x DisplayPort multiviewer
  • Storage: 3 x 3TB internal drive (capacity varies by format, resolution and file specification)
  • A/V Standards: 3G-SDI video conforms to SMPTE 424M (Level A)
    HD-SDI Video conforms to SMPTE 292M
    SD Video conforms to SMPTE 259M and ITU-RE BT.656
  • Macros: Record, store, edit, and automate commands and user-configured operation sequences, including support for cross-platform automation between supported systems

Physical

  • Chassis: 3Play 3P1 - 2RU chassis with 400W PSU and multi-tiered hardware and software fail-safe
  • Size: 19.0 x 3.5 x 19.57 in (48.3 x 8.9 x 49.7 cm) with rack ears attached
  • Weight: 12kg
